High Precision Screw Fastening Machine for Automated Screw Assembly
with Complex Positioning
The screw machine is a dual screw driver, dual platform, and
suction screw feeder automatic screw locking machine, it use touch
scrren and manual moving the screw head to do the location, its a
much easy programming type, save much programming time.
Its a new type screw locking machine which can replace the
traditional manual teaching pandent programming machine, it's
widely used in the electronics industry.
Compatible for screws from M1 to M6, other special screws, also can
be customization.
Features
1, Suction type feeding, with single screw feeder and single
locking head.
2, Desktop and visible operation, can connect the automatic
production line.
3, 6 Axis operation, moving range 600*300*300*100*100mm.
4, Support multiple screw bins in suction mode.
5, Double working station, improve the production efficiency and
reduce labor cost.
6, Easy adaptability for M1-M6, just by changing screw
guider(Customization available).
7, Easy operation, operator can operate several machines at the
same time.
8,The machine can store hundreds of processing files, each file can
support 1000 screw bits, you can call it out when you use it.
Functions and applications:
Used in automated screw assembly scenarios that require high
precision and complex spatial positioning.
It can achieve coordinated movement of 3 linear axes and 3 rotary
axes to flexibly position screws.
It is widely used in complex product assembly in the automotive,
electronics, home appliances and other industries.
Mechanical structure:
6 independently controllable joints, including 3 linear axes and 3
rotary axes.
It is driven by a servo motor and equipped with a high-precision
encoder to achieve precise positioning.
A screwdriver head is installed at the end of the robotic arm to
achieve high-precision tightening of screws through precision
control.
Equipped with an automatic screw supply device to complete the
entire screw assembly process.
Control system:
Industrial-grade PLC or motion controller is used for centralized
control and program programming.
It can realize 3D spatial trajectory planning to ensure smooth and
collision-free movement of the robotic arm.
Equipped with a human-machine interface, it can realize the design,
storage and call of operating programs.
It has real-time monitoring and feedback in multiple dimensions
such as torque, position, and speed.
Performance characteristics:
6 degrees of freedom, which can realize a variety of complex
spatial postures for screw assembly.
High repeatability, usually within ±0.1mm.
High working efficiency, up to 80-120 times/minute screw assembly
speed.
Suitable for screws of different sizes and materials, strong
compatibility.
High degree of automation, greatly improving production efficiency
and product quality.
Specification
| Model | HS-DH6331 |
| Production name | Automatic Screw Locking Machine |
| Moving range(X/Y1/Y2/Z) | 600*300*300*100*100mm |
| X/Y1/Y2 axis moving speed | Closed loop motor :1-800mm/s |
| Z axis moving speed | Closed loop motor: 1-300mm/s |
| X/Y1/Y2 axis max load | Closed loop motor: 5KG |
| Z axis max load | Closed loop motor: 3KG |
| Power supply | AC110V/220V, 50/60Hz |
| Repeat accuracy | ±0.02mm |
| Document support | CAD CorelDraw |
| Suitable screws | M1-M6 |
| Machine dimension8 | 880*585*800mm |
| Machine weight | 120kg |
Main parts brand
1, Motor: Shinano
2, Guide: Hiwin
3, Photoelectric switch: Omron
4, Power supply: Meanwell
Item | Screw Locking Machine |
Package | 1 set into one wooden carton as safety condition |
External Dimension | 8800*585*800mm |
Weight | about 120kgs |
Delivery | about 15-20 working days |
Payment | D/P, T/T, Western Union, MoneyGram |
Port | Shenzhen |
| A.By Courier: 4-7 Working days by special offer |
B.By Air: 7 Working days at appointed airport |
C.By Sea: 20-25 Working days at appointed port |
