    High Precision ESD Brush PCB Surface Dust Cleaner PCB Handling Equipment With Static Eliminate Function

    Ask Lasest Price
    Brand Name : HSTECH
    Model Number : HS-460BC
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 50 sets per month
    Delivery Time : 15~20 work days
    • Product Details
    • Company Profile

    High Precision ESD Brush PCB Surface Dust Cleaner PCB Handling Equipment With Static Eliminate Function

    High Precision ESD Brush PCB Surface Dust Cleaner PCB Handling Equipment With Static Eliminate Function


    Products Description

    PCB Surface Dust Cleaner:


    This machine is used between PCB loader and screen printer, with brush and sticker roller to clean the dust,electricity static on the surface of the PCB.


    The fully automatic PCB board surface cleaning machine is suitable for online cleaning of small board chips, dust, fibers, hair, skin debris, metal particles and other foreign matter on the surface of PCB pads before solder paste printing or adhesive coating to ensure that the PCB surface is in a Clean status.


    Principle and working mode:

    Principle of electrostatic dust removal: Use electrostatic adsorption force to adsorb and collect dust particles on the surface of PCB. Common electrostatic dust removal methods include ion blowers and electrostatic dust collectors.


    Principle of air flow sweeping: Use compressed air to generate high-speed airflow to sweep and absorb dust on the surface of PCB. This method does not require an electrostatic field, but requires a matching vacuum collection system.


    Main equipment components:
    Dust removal room/isolation workbench: closed working environment to reduce external dust pollution
    Dust removal device: electrostatic generator or compressed air system
    Dust collection device: electrostatic collection plate or vacuum cleaner
    Conveying device: conveyor belt for automatic entry and exit of PCB


    Main performance indicators:
    Cleaning efficiency: can remove more than 99% of PCB surface dust
    Cleanliness: PCB surface particle size is less than 5μm
    Cleaning speed: one-time cleaning time is less than 10 seconds
    Cleanliness level: meet the ISO14644-1 Class 100 clean room standard


    Application scenarios and advantages:
    PCB manufacturing link: improve the yield rate of each PCB process
    PCB assembly link: ensure the cleanliness of PCB during mounting and welding
    Repair and rework: local cleaning of assembled PCBs
    Non-destructive cleaning: will not cause any scratches or damage to the PCB surface


    Purchase suggestions:
    Choose the appropriate equipment model according to PCB size and production scale
    Pay attention to the equipment's cleaning efficiency, cleaning degree and cleaning speed indicators
    Evaluate the equipment's automation level and ease of operation
    Consider the equipment's energy consumption, noise, floor space and other usage costs


    Specification


    ModelHS-250BCHS-330BCHS-390BCHS-460BC
    PCB dimension(50*50)~(350*250)(50*50)~(460*330)(50*50)~(530*390)(50*50)~(530*460)
    Machine dimension555*820*1350555*900*1350555*960*1350555*1030*1350
    Weight80kg90kg100kg110kg

    PCB thickness0.4~5mm
    Power supplyAC100~230V,single phase,300A
    Air supply0.4~0.6Mpa
    Cleaning brushtop 2 pcs
    Sticker rollertop 1 pc
    BrushESD,high precision brush
    If with dust collectorYes
    Transport speed0~9m/min,adjustable
    Transport heightstandard 900±20mm
    DirectionL to R, or R to L,optional
    Cycle timeAround 8s

    Features


    1, Ultra-high speed anti-static spiral brush, vacuum extraction clean Method .
    2, Special corresponding SMT printing, mount before and after AI plug-in PCB board on the back of the foreign body clean.
    3, Equipped with the static eliminate function, completely eliminate electrostatic interference.
    4, Touching clean method, cleanness above 99%.
    5, Designed to clean the roller to ensure efficient, stable, lasting cleaning effect.
    6, Mechanical parts draw-out design, maintenance is simple.
    7, Interface display in English and Chinese, interface operation convenient and simple.

    High Precision ESD Brush PCB Surface Dust Cleaner PCB Handling Equipment With Static Eliminate Function


    Easy To Install Disassemble Ultra Sound Cleaner Multiple Sizes PCB Cleaning Machine HS-460BC 1


    Easy To Install Disassemble Ultra Sound Cleaner Multiple Sizes PCB Cleaning Machine HS-460BC 2

    Packing & Delivery
    Item
    PCB Surface Dust Cleaner
    Package
    1 set into one wooden carton as safety condition
    External Dimension
    555*820*1350mm
    Weight
    about 80-110kgs
    Delivery
    about 15-20 working days
    Payment
    D/P, T/T, Western Union, MoneyGram
    Port
    Shenzhen
    Shipment
    A.By Courier: 4-7 Working days by special offer
    B.By Air: 7 Working days at appointed airport
    C.By Sea: 20-25 Working days at appointed port

    Easy To Install Disassemble Ultra Sound Cleaner Multiple Sizes PCB Cleaning Machine HS-460BC 3

    Easy To Install Disassemble Ultra Sound Cleaner Multiple Sizes PCB Cleaning Machine HS-460BC 4

    Easy To Install Disassemble Ultra Sound Cleaner Multiple Sizes PCB Cleaning Machine HS-460BC 5


    COMPANY PROFILE


    Shenzhen Hansome Technology Co.,Ltd(HSTECH)is a professional professional SMT board handlingequipment(Loader,Unloader, Buffer, Conveyor,etc)manufacturer, We are a high-tech enterprise with independent intellectual propertyrights,the company is mainly engaged in the research and development, productionand sales of sMT/THT production line board handling equipment.We have professional technicians & sales,relies on high-tech and tries our best tosupply high efficient and reliable board handling to our customers. At the same time,our experienced engineering team always grasps smart factory's developing directionupdates the products and technical according to the market demand, pursuit to makemore automation and cost-effective product all the time, we also do the OEM basedon different needs of our customer.
