    Touch Screen 4Axis Glue Dispensing Machine Optional 1-4 Head Dispensing Device

    Ask Lasest Price
    Brand Name : HSTECH
    Model Number : HS-D441
    Certification : CE
    Price : Negotiable
    Payment Terms : D/P, T/T, Western Union, MoneyGram
    Supply Ability : 500 pcs per month
    Delivery Time : 15~20 work days
    • Product Details
    • Company Profile

    Touch Screen 4Axis Glue Dispensing Machine Optional 1-4 Head Dispensing Device

    Touch Screen 4Axis Glue Dispensing Machine Optional 1-4 Head Dispensing Device

    Introduce


    The glue dispensing machine, also known as glue coating machine, glue dripping machine, glue dispensing machine, glue filling machine, etc., specializes in controlling fluids. The automated machine that drips and coats the fluid on the surface of the product or inside the product can realize three-dimensional and four-dimensional path dispensing, precise positioning, precise glue control, and no stringing, no glue leakage, and no glue dripping. The dispensing machine is mainly used to accurately point, inject, apply and drip glue, paint and other liquids in the product process to the precise position of each product. It can be used to realize dotting, drawing lines, circles or arcs.

    Machine feature
    1. PC computer LCD screen operation, easy to program, easy to learn and understand;


    2. It has the functions of drawing points, lines, faces, arcs, circles, and continually tween of irregular curves to realize any 3D non-planar track path;


    3. The size of the glue, the speed of the glue, the time of dispensing, and the time of stopping the glu e can all be parameterized;


    4. With the special dispensing controller, the glue output is stable, the glue is clean and the glue is not leaked;


    5. Quickly dot, draw lines and draw circles in the inner, outer wall, vertical surface, gap and spherical surface of the product;


    6. According to the needs of customers, it can be equipped with fixtures, glue guns, controllers, heatingtemperature control devices, etc.


    7. Optional 1-4 head dispensing device, multiple glue guns at the same time to double the work efficiency;


    8. The software has functions such as regional display, translation rotation operation, etc.


    9. Adopt trapezoidal acceleration and deceleration, speed preview, micro line interpolation and other technologies;


    10. Configure high-speed, low-noise Japanese stepping motor with precise positioning, quick response,stable performance and long service life.

    Specification
    ModelHS-D441
    Power supply110V/220V 50-60Hz 350W
    Glue Mixing Ratio1:1-10:1/Customizable
    Dispensing Speed10-150g/5s(based on 1:1 glue proportion)
    Dispensing PrecisionGlue Amount±1%, Glue Proportion±1%
    X/Y/Z Working Range400*400*100mm(Z axis can be rotated)
    XYZ SpeedMax 300mm/s
    Drive SystemStepping Motor + Timing Belt
    Repeatability±0.02mm
    PatternLines, Circles, Arcs, Continuous Paths, 3D Linear Interpolation
    Potting PrecisionAmount±1%, Ratio:±1%
    ProgrammingTeach Pendant
    ControlPLC
    Leak-proof FunctionValve with Vacuum Device
    Document SupportCAD, CorelDRAW
    Weight40kg
    Dimension(L*W*H)616*685*645mm

    Application

    Epoxy Glue Dispensing Machine Teach Pendant Stepping Motor With Vacuum Device 0

    PC Computer LCD Screen Operation Special Dispensing Controller 4Axis Glue Dispensing Machine 1

    PC Computer LCD Screen Operation Special Dispensing Controller 4Axis Glue Dispensing Machine 2
