    Blade Moving 600mm Cutting Length V-cut PCB Separating Machine

    Ask Lasest Price
    Brand Name : HSTECH
    Model Number : HS-206
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 100pcs per week
    Delivery Time : 5-7 work days
    • Product Details
    • Company Profile

    Blade Moving 600mm Cutting Length V-cut PCB Separating Machine

    Blade Moving 600mm Cutting Length V-cut PCB Separating Machine


    Specification


    ModelHS-203HS-206
    PrincipleBoard insert to the V-slot,blade moving cutting
    BladeBottom linear balde, upper circular blade
    VoltageAC110V/220V 50/60Hz
    Blade size(circular blade)ϕ125mm*30mm*3mm
    Blade size(linear blade)420mm×65mm×6mm
    Max cutting length5~400mm5~600mm
    PCB thickness0.8~3mm
    Separation speed300~500mm/second(adjustable)
    Separation widthBest 1~200mm
    Components height≤32mm( or customized)
    Power60W
    Machine dimension710x450x420mm900x450x420mm
    Weight55kg75kg

    Blade Moving 600mm Cutting Length V-cut PCB Separating Machine
