SMD Component Counter With Conductive/Non-Conductive Carrier Tape
Introduction
The embossed carrier tape is used for packing the components into
reels and protect from physical damage, it made of polystyrene,
polycarbonate and PET. Carrier tapes with varying conductive and
anti-static qualities to suit different components applications.The
Carrier tape has pockets that are shaped to match the contours of
the component to be carried. The width of carrier tape is between 8
and 104 mm, we also can custom for customers based on their demand.
Carrier tape specification
| Name | Carrier tape |
| Material | PS,PC,PET |
| Type | Conductive(antistatic)and non-conductive(non-antistatic) |
| Color | Black, Transparent |
| Width | 8-104mm |
| Thickness | 0.3-2.0mm,also customized for customers |
| Application | Smd components, electronic parts, hardware parts |
| Meter for per reel | According to the components |
| Cover tape | Cold sealing/hot sealing options |
| Reels | Available |
The whole packing reels including the carrier tape, cover tape and
external reel, customers use the manual or automatic tape and reel
machine to pick the components into the carrier tape, at the same
time use the cover tape to cover the components tightly to protect
and fix the components in the tape, at last packing to a whole
reel.
Carrier tape size and it matched cover tape
Each carrier tape has it matched cover tape, the cover tape has the
cold sealing and hot sealing options during the components
packing,also the cover tape has the ESD options. Below is the
dimension of the carrier tape and it matched cover tape diagram.
| Carrier Tape(mm) | 8 | 12 | 16 | 24 | 32 | 44 | 56 | 72 | 88 | 104 |
| Cover Tape(mm) | 5.4 | 9.3 | 13.3 | 21.3 | 25.5 | 37.5 | 49.5 | 65.5 | 81.5 | 97.5 |
Reels
We also manufacture reels by injection moulding. They are made of
polystyrene in different sizes and designs. We can also produce
them in anti-static or conductive options under the requirements.
Application
This carrier tape is widely used in IC, capacitors, resistors,
connectors, micro-transformers, inductors, electronic switches,
diodes, transistors, LED chip, Low Power LEDs, Mid/High Power
Packages, Domed Packages, LED Modules, Lenses, LED Die,crystals and
other surface-mount components packaging, to meet the requirements
of efficient, fast and miniaturized production of modern electronic
products. Applicable to all belts, uniform density, consistent peel
strength, anti-static function. Mainly used in connectors, chip
capacitors, resistors, integrated blocks, chips can be used with
PS, PC, PVC, PET material carrier tape.
We supply high quality embossed carrier tapes and custom carrier
tapes according to customers's demand.
If you need a carrier tape to allow parts to be placed and sealed
to go onto a pick and place system, then we have options for you.
